Drive Belt: Service and Repair

V-belt

REMOVAL

1. Fit the tool to the belt tensioner mounting bolt.

2. Turn the tool clockwise, and loosen the V-belt to remove.
3. Remove the V-belt cover.

INSTALLATION

1. Install in the reverse order of removal.

INSPECTION
