Reno L4-2.0L (2006)
Alignment: Service and Repair
Front
Front Camber and Caster Check
Front Camber and Caster Check
The front camber and caster are not adjustable. Jounce the bumper three times before measuring the camber or the caster in order to prevent an
incorrect reading. If the front camber or caster measurements deviate from the specifications, locate and replace or repair any damaged, loose, bent,
dented, or worn suspension part. If the problem is body related, repair the body.
Front Toe Adjustment
Front Toe Adjustment
1. Disconnect the outer tie rods from the knuckle assemblies.
NOTE: No person in vehicle and full tank of fuel.
2. Turn the right and the left outer tie rods and the adjuster nuts to align the FRONT TOE to 0°00 ± 10'.
Reconnect the outer tie rods to the knuckle assemblies.
NOTE: In this adjustment, the right and the left tie rods must be equal in length, or the tires will wear unevenly.
