Brake Fluid: Specifications (page 4 of 5) – Suzuki Verona L6-2.5L (2005)

7. Remove the brake fluid reservoir from the master cylinder body by tilting the reservoir and pulling it upward.

8. Remove and discard the brake fluid reservoir seals from the master cylinder body.

Brake Fluid Reservoir Installation

1. Lubricate the new brake fluid reservoir seals with clean brake fluid.
2. Install the brake fluid reservoir seals into the master cylinder body.

3. Install the brake fluid reservoir onto the master cylinder body.

4. For vehicles with the manual transaxle, install the clutch hose connection to the master cylinder with the clip.
5. Add the brake fluid.
6. Raise and suitably support the vehicle.
7. Bleed the brake system.
8. Lower the vehicle.
