Vitara 2WD V6-2.5L (2004)
Fluid - Differential: Service and Repair
Gear Oil Inspection and Change
NOTE:
^
Hypoid gear oil must be used for differential.
^
It is highly recommended to use SAE 80W-90 viscosity.
1) Before oil change or inspection, be sure to stop engine and lift up vehicle horizontally.
2) Check oil level and existence of leakage. If leakage is found, correct its cause.
3) Drain old oil and pour proper amount of gear oil as specified (roughly up to level hole).
4) Torque drain and level / filler plugs to specification.
Oil capacity: 2.2 L (4.6/3.9 US/Imp. pt.)
