Vitara 4WD L4-2.0L (2003)
-
Green Dot:
Battery is sufficiently charged for testing.
-
Dark:
Battery must be charged before testing.
If there is a cranking complaint, battery should be tested as described in "Battery Inspection:".
Charging and electrical systems should also be checked at this time.
-
Clear or Light Yellow:
This means that fluid level is below the bottom of hydrometer. Its possible cause is excessive or prolonged charging, a broken case, excessive
tipping or normal battery deterioration.
When the battery is found in such condition, it is possible that high charging voltage is caused by the faulty charging system and therefore,
charging and electrical systems need to be checked. If there is a trouble in cranking and its cause lies in the battery, it should be replaced.
