Drive Belt: Specifications
Belt Deflection

Belt Deflection

Alternator Belt

Used Belt Deflection

0.24 - 0.32 in









New Belt Deflection

0.20 - 0.27 in











A/C Comp. And/or P/S Pump Belt Used Belt Deflection

0.24 - 0.35 in









New Belt Deflection

0.24 - 0.35 in
