Vanity Lamp: Diagrams

Vanity Mirror Dome Lamp Switch (UUC)

Connector Part Information

OEM: 12047782
Service: 12117371
Description: 3-Way M Metri-Pack 150 Series (BK)

Terminal Part Information

Terminal/Tray: See Terminal Repair Kit
Core/Insulation Crimp: See Terminal Repair Kit
Release Tool/Test Probe: See Terminal Repair Kit

Vanity Mirror Dome Lamp Switch (UUC)

Vanity Mirror Map Lamp (UUC)
