4 Runner 2WD V6-4.0L (1GR-FE) (2006)
/Page-993001.png)
Control Arm: Service and Repair
Rear
Upper Control Arm Assembly Replacement
REPLACEMENT
1. REMOVE REAR WHEEL
2. DISCONNECT HEIGHT CONTROL SENSOR LINK SUB-ASSEMBLY REAR (W/ AIR SUSPENSION)
3. REMOVE UPPER CONTROL ARM ASSEMBLY
a. Remove the nut, washer and bolt from rear axle housing.
HINT: While fixing the bolt, turn and remove the nut.
