4 Runner 4WD V6-4.0L (1GR-FE) (2006)
/Page-1212001.png)
Cellular Phone Microphone: Service and Repair
AMPLIFIER MICROPHONE ASSEMBLY
REPLACEMENT
HINT: Installation is in the reverse order of removal.
1. REMOVE ROOF CONSOLE BOX ASSEMBLY
2. REMOVE AMPLIFIER MICROPHONE ASSEMBLY
(a) Remove the 4 screws.
(b) Disconnect the connector.
(c) Disengage the 2 claws and remove the amplifier microphone assembly.
