Camry Coupe 2-Door V6-3.0L (1MZ-FE) (1996)

Page 1
background image

Data Link Connector: Component Locations

Data Link Connector 1 Is Mounted On The Intake Manifold

Data Link Connector 3 (DLC3) Is Located Inside The Fuse Panel
