Camshaft Bearing: Specifications



RH Camshaft Bearing Cap Bolts

Torque

16 Nm (12 ft.lb)









Intake Sequence

---











Exhaust Sequence ---











LH Camshaft Bearing Cap Bolts

Torque

16 Nm (12 ft.lb)









Intake Sequence

---













Exhaust Sequence ---













Exhaust
