Camry XLE Sedan V6-3.0L (1MZ-FE) (1998)

Page 1
background image

Fuel Supply Line: Specifications



No.1 Fuel Pipe To Intake Manifold

14 ft.lb







Fuel Line (Union Bolt Type)

21 ft.lb







Fuel Line (Flare Nut Type)  Using SST

21 ft.lb
