Idle Speed/Throttle Actuator - Electronic: Electrical Specifications



Resistance

Cold

17.0 - 24.5 ohms at 14 - 122 deg F

Note: Measured between +B and other terminals.











Hot

21.5 - 28.5 ohms at 122 - 212 deg F
