Alignment|Service and Repair > < Steering/Suspension - Vehicle Pull Repair Supplement|Page 848

Celica L4-1.8L (1ZZ-FE) (2004)

Page 1
background image

Alignment: Specifications

*1: Front measuring point

Measure the distance from the ground to the head center of the front side lower suspension arm mounting bolt.

*2: Rear measuring point

Measure the distance from the ground to the center of the lower suspension arm suspension member side set bolt.
