Leak Detection Solenoid: Testing and Inspection

VSV FOR PRESSURE SWITCHING VALVE

INSPECTION

1. REMOVE VSV

2. INSPECT VSV FOR OPEN CIRCUIT

Using an ohmmeter, check that there is continuity between the terminals.

Resistance:
If there is no continuity, replace the VSV.

3. INSPECT VSV FOR GROUND

Using an ohmmeter, check that there is no continuity between each terminal and the body.
If there is no continuity, replace the VSV.

4. INSPECT VSV OPERATION

a. Check that air does not flow from ports E to F.
