Celica GT L4-1.8L (1ZZ-FE) (2001)

Page 4
background image

DISASSEMBLY

w/ ABS:
REMOVE ABS SPEED SENSOR
(a) Using a pin punch and hammer, drive out the 2 pins and remove the 2 attachments from SST.

SST 09520-00031 (09520-00040, 09521-00020)
