Celica GT L4-1.8L (1ZZ-FE) (2001)
/Page-779002.png)
Total No. Of Coils
12.61 mm
Accumulator No.1 Piston
Yellow
Free Length
31.0 mm
Coil Outer Diameter 10.0 mm
Total No. Of Coils
9.61 mm
Lower Valve Body
Primary Regulator Valve
None
Free Length
59.90 mm
Coil Outer Diameter 21.90 mm
Total No. Of Coils
7.57 mm
Lock-Up Control Valve
None
Free Length
20.90 mm
Coil Outer Diameter 5.55 mm
Total No. Of Coils
12.86 mm
3-4 Shift Valve
None
Free Length
25.98 mm
Coil Outer Diameter 9.80 mm
Total No. Of Coils
7.90 mm
1-2 Shift Valve
None
Free Length
25.98 mm
Coil Outer Diameter 9.80 mm
Total No. Of Coils
7.90 mm
Accumulator Control Valve
Yellow
Free Length
27.10 mm
Coil Outer Diameter 11.0 mm
Total No. Of Coils
6.68 mm
Pressure Relief Valve
None
Free Length
25.55 mm
Coil Outer Diameter 10.30 mm
Total No. Of Coils
9.70 mm
Valve Body Key
Upper Valve Body
3-4 Shift Timing Valve
Height
23.0 mm
Thickness
3.2 mm
Low Modulator Valve
Height
23.0 mm
Thickness
3.2 mm
2-3 Shift Valve
Height
23.0 mm
Thickness
3.2 mm
Coast Relay Valve
Height
10.0 mm
Width
5.0 mm
Thickness
3.2 mm
Solenoid Modulator Valve and
Height
28.5 mm
