Celica GT L4-1.8L (1ZZ-FE) (2001)
/Page-780004.png)
Torque: 10 Nm (100 kgf-cm, 8 ft. lbs.)
17. CONNECT 5 SHIFT SOLENOID VALVE CONNECTORS
18. INSTALL OIL STRAINER
a. Coat a new O-ring with ATF.
b. Install the O-ring to the oil strainer.
c. Install the oil strainer with the 3 bolts.
Torque: 11 Nm (110 kgf-cm, 8 ft. lbs.)
19. INSTALL MAGNET IN OIL PAN
Install the 2 magnets in the oil pan, as shown in the illustration.
20. INSTALL OIL PAN
Install the oil pan and a new gasket with the 19 bolts.
Torque: 7.8 Nm (80 kgf-cm, 69 inch lbs.)
21. INSTALL DRAIN PLUG
Install a new gasket and drain plug.
Torque: 49 Nm (500 kgf-cm, 36 ft. lbs.)
22. FILL ATF AND CHECK ATF LEVEL
23. INSTALL LH ENGINE UNDER COVER
