Celica GT Liftback L4-2164cc 2.2L DOHC MFI (1998)
Tachometer: Testing and Inspection
INSPECT TACHOMETER ON VEHICLE
a. Connect a tune-up test tachometer, and start the engine.
NOTE: Reversing the connection of the tachometer will damage the transistors and diodes inside.
b. Compare the tester indications with tachometer indications.
If error is excessive, replace the tachometer.
RPM (DC 13.5 V, 25 °C (77 °F))
