Corolla CE Sedan L4-1794cc 1.8L DOHC MFI (2001)
ABS Light: Testing and Inspection
CIRCUIT DESCRIPTION
If the ECU detects trouble, it lights the ABS warning light while at the same time prohibiting ABS control. At this time, the ECU records a DTC in
memory.
Connect terminals Tc and E1 of the DLC1 make the ABS warning light blink and output the DTC.
Wiring Diagram
