Echo L4-1.5L (1NZ-FE) (2000)

  • Powertrain Management
  • Tune-up and Engine Performance Checks
  • Fuel Pressure
  • System Information
  • Specifications
  • Pressure Specification

Page 1
background image

Fuel Pressure: Specifications
Fuel System Pressure

Fuel System Pressure

Idle Pressure

301-347 kpa (3.1-3.5 kgf/cm2, 44-50 PSI)







5 Minutes After Engine Has Stopped 147 kpa (1.5 kgf/cm2, 21 PSI) Or More
