Accessory Control Display: Service and Repair
Multi-Display
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER
3. REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY
a. Remove the 6 bolts.
b. Disconnect the connectors and remove the integration control and panel assembly.
4. REMOVE MULTI-DISPLAY
a. Remove the 7 bolts and the multi-display controller bracket A.
b. Remove the 7 bolts and the multi-display controller bracket B.
INSTALLATION
1. INSTALL MULTI-DISPLAY
