Highlander 2WD V6-3.3L (3MZ-FE) Hybrid (2006)
_hybrid/Page-1173003.png)
3. SEPARATE REAR STABILIZER LINK ASSEMBLY
a. Support the rear axle carrier with a jack using a wooden block to avoid damage.
b. Remove the nut and separate the rear stabilizer link assembly from the rear shock absorber.
HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.
4. SEPARATE REAR SPEED SENSOR
a. 2WD: Remove the 2 bolts, and disconnect the rear brake flexible hose and rear speed sensor from the rear shock absorber with coil spring and
rear axle carrier.
NOTICE: Be sure to remove the rear speed sensor from the rear shock absorber with coil spring.
