Matrix 2WD L4-1.8L (1ZZ-FE) (2003)

Page 1
background image

Alignment: Specifications



Vehicle height

D - C

41 mm











Toe-in inspection

Toe-in A + B

0 deg 16' +/- 16'

total













C - D

2.8 +/- 2.7 mm















Camber

-1 deg 27' +/- 30'











Right-left error

30' or less
