Prius L4-1.5L (1NZ-FXE) (Hybrid) (2003)
![background image](/toyota/prius/l4-1.5l_(1nz-fxe)_(hybrid)/Page-117001.png)
Battery Temperature Sensor/Switch: Testing and Inspection
INSPECTION
INSPECT SPEED SENSOR (RESOLVER) AND TEMPERATURE SENSOR
Using an ohmmeter, measure resistance at each terminals.
HINT: The range of standard values for the temperature sensor is shown in the illustration.
