Control Arm: Service and Repair
Front Suspension Lower No. 1 Arm

FRONT SUSPENSION LOWER NO. 1 ARM

Components

REMOVAL

1. REMOVE FRONT WHEEL
2. REMOVE HOOD SUB-ASSEMBLY

a. Remove the hood.
