Sequoia 2WD V8-4.7L (2UZ-FE) (2003)
/Page-986001.png)
Hydraulic Control Assembly - Antilock Brakes: Service and Repair
Disassembly and Assembly
DISASSEMBLY
1. REMOVE ACTUATOR BRACKET
a. Remove the 3 bolts and actuator bracket.
Torque: 9.5 Nm (97 kgf-cm, 84 inch lbs.)
b. Remove the 3 cushions and 3 spacers from the actuator bracket.
2. REMOVE SKID CONTROL ECU
Using an E5 torx wrench, remove the 4 screws and skid control ECU.
Torque: 1.8 Nm (18 kgf-cm, 16 inch lbs.)
