Sequoia 4WD V8-4.7L (2UZ-FE) (2006)
/Page-415002.png)
a. Disconnect the 2 camshaft oil control valve connectors.
b. Remove the bolt, camshaft oil control valve and Oring.
Torque: 7.5 N.m (76 kgf.cm, 66 in.lbf)
c. Remove the O-ring from the each camshaft oil control valve.
HINT: At the time of installation, please refer to the following items. Use a new O-rings.
INSTALLATION
Installation is in the reverse order of removal.
