T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)
/Page-256004.png)
4. REMOVE PISTON AND CONNECTING ROD ASSEMBLIES
(a) Using a ridge reamer. remove the all carbon from the top of the cylinder.
(b) Cover the connecting rod bolts with a short piece of hose to protect the crankshaft from damage.
(c) Push the piston, connecting rod assembly and upper bearing through the top of the cylinder block.
HINT:
-
Keep the bearings, connecting rod and cap together.
-
Arrange the piston and connecting rod assemblies in correct order.
