T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)
![background image](/toyota/t100_pickup_4wd/v6-180.5_2959cc_3.0l_sohc_(3vz-e)/Page-257004.png)
(k) Completely remove the Plastigage.
REMOVE CRANKSHAFT
(a) Lift out the crankshaft.
(b) Remove the upper main bearings and upper thrust washers from the cylinder block.
HINT: Arrange the main bearings and thrust washers in correct order.
