T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)
CRANKSHAFT INSPECTION
1.
CHECK CONNECTING ROD THRUST CLEARANCE
(a).
Using a dial indicator, measure the thrust clearance while moving the connecting rod back and forth.
Standard thrust clearance:
0.150-0.330 mm (0.0059-O.0130 in)
Maximum thrust clearance:
0.38 mm (0.0150 in)
If the thrust clearance is greater than maximum, replace the short block assembly
2.
REMOVE CONNECTING ROD CAPS
(a).
Using a punch or numbering stamp, mark the connecting rod and cap to ensure correct reassembly.
(b).
Remove the connecting rod cap nuts.
(c).
Using a plastic.faced hammer, lightly tap the connecting rod bolts and. lift off the connecting rod cap.
NOTE:
Keep the lower bearing inserted with the connecting rod cap.
