T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)

Page 1
background image

Auxiliary Air Valve (Idle Speed): Locations

Auxiliary Air Valve Location

The Auxiliary Air Valve is located on the bottom of the Throttle Body.
