T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)
Suspension Spring ( Coil / Leaf ): Service and Repair
Leaf Spring
Fig. 5 Exploded View Of Leaf Spring Rear Suspension.
1.
Raise rear of vehicle and place stands under frame and rear axle housing.
2.
Disconnect shock absorber from upper and lower mountings and remove shock absorber from vehicle, Fig. 5.
