Tacoma 2WD L4-2.4L (2RZ-FE) (1996)

Page 1
background image

Camshaft Bearing: Specifications

TIGHTENING SPECIFICATIONS

Camshaft Bearing Cap Bolts ........................................................................................................................................................  15.5 Nm (12 ft. lbs.)

Exhaust Camshaft Bearing Cap Removal Sequence

Intake Camshaft Bearing Cap Removal Sequence

Intake Camshaft Bearing Cap Tightening Sequence

Exhaust Camshaft Bearing Cap Tightening Sequence
