Tercel Sedan L4-1456cc 1.5L SOHC (3E) (1988)

Page 1
background image

Timing Belt Tensioner: Specifications



Tensioner Spring

Free Length

38.8 mm









Installed Tension

18.3 lbf at 2.157 in
