Heater Circuit Breaker|Page 1933 > < Electrical - SRS And HV Wiring Repairs

Tercel Sedan L4-1456cc 1.5L SOHC (3E) (1988)

  • Power and Ground Distribution
  • Circuit Breaker
  • Component Information
  • Locations
  • Heater Circuit Breaker

Page 1
background image

Circuit Breaker: Locations
Heater Circuit Breaker

Passenger Compartment Components.

 Behind RH Kick Panel

Applicable to:  Tercel Wagon
