Tundra 4WD V6-3.4L (5VZ-FE) (2004)
/Page-1474001.png)
Brake Warning Indicator: Testing and Inspection
Brake Warning Light Circuit
Antilock Brake (ABS) System
BRAKE Warning Light Circuit
CIRCUIT DESCRIPTION
The BRAKE warning light turns on when the brake fluid is insufficient, the parking brake is applied or the EBD is defective.
Wiring Diagram
