Tundra Access Cab SR5 2WD V6-3.4L (5VZ-FE) (2000)
![background image](/toyota/tundra_access_cab_sr5_2wd/v6-3.4l_(5vz-fe)/Page-1214001.png)
Refrigerant Pressure Sensor / Switch: Service and Repair
REMOVAL
1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM
HINT: At the time of installation, please refer to the following item.
Evacuate sir from refrigeration system.
Charge system with refrigerant and inspect for leakage of refrigerant.
Specified amount: 600 ± 50 g (21.16 ± 1.76 oz.)
2. REMOVE PRESSURE SWITCH FROM LIQUID TUBE
Disconnect the connector and remove the pressure switch.
Torque: 10 Nm (100 kg.cm, 7 ft.lb)
HINT:
-
Lock the switch mount on the tube with an open end wrench, being careful not to deform the tube, and remove the switch.
-
At the time of installation, please refer to the following item.
Lubricate a new O-ring with the compressor oil and install them to the switch.
INSTALLATION
Installation is in the reverse order of removal.
