Tundra Access Cab SR5 2WD V6-3.4L (5VZ-FE) (2000)
/Page-750001.png)
Clutch: Specifications
O/D Direct Clutch
Clutch Drum Bushing Inside Diameter
Maximum
27.11 mm
O/D Direct Clutch Piston Stroke
1.85 - 2.15 mm
O/D Direct Clutch Drum Standard Distance
15.5 - 16.5 mm
O/D Planetary Gear Bushing
Maximum
11.27 mm
Planetary Pinion Gear Thrust Clearance
Standard
0.20 - 0.60 mm
Maximum
1.00 mm
Flange Thickness
No.16
3.6 mm
No.17
3.5 mm
No.18
3.4 mm
No.19
3.3 mm
No.20
3.2 mm
No.21
3.1 mm
Piston Return Spring Standard Free Length
15.8 mm
Direct Clutch
Piston Stroke
1.37 - 1.60 mm
Drum Bushing Inside Diameter
53.99 mm
Flange Thickness
No.33
3.0 mm
No.32
3.1 mm
No.31
3.2 mm
No.30
3.3 mm
No.29
3.4 mm
No.28
3.5 mm
No.27
3.6 mm
No.34
3.7 mm
