ZF Servotronic Steering (Function, Electronic): Description and Operation

Function, Electronic

The speed signal is fed to the Servotronic control unit.

Using the actual speed signal and the characteristic curve programmed in the microprocessor, the control unit determines the electric current variable for the electro - hydraulic converter.

This converter (solenoid valve) is attached directly to the steering gear valve housing. It converts the electrical signal into the corresponding hydraulic control variable, which determines the reaction pressure and thus the steering force.

The result of this is that the vehicle is easy to steer at a standstill and when parking.

As speed increases, the actuating force required for the steering wheel increases. Due to this higher actuating force, the sensation of road contact is left intact.
