Eurovan V6-2.8L (AXK) (2001)
/Page-1194001.png)
Ball Joint: Specifications
1 - Hex-nut, tighten to 100 Nm
^
Always replace after disassembly
6 - Hex bolt, 60 Nm
^
M 1 2 x 1.5 x 22
8 - Hexnut, tighten to 130 Nm
^
Only tighten when vehicle is standing on its wheels.
20 - Self locking hex nut
^
60 Nm + 90° (1/4 turn)
^
Always replace after disassembly
21 - Socket head bolt M12 x 1.5 x 30
^
90 Nm + 90° (1/4 turn)
^
Always replace after disassembly
^
Use socket head wrench 14 (e.g. Hazet 990)
22 - Hex-nut, tighten to 160 Nm
24 - Hex bolt
^
M 14 x 1.5 x 82
