Wiper Arm: Locations

Windshield Wiper System, Assembly

CAUTION!
Before beginning repairs on the electrical system:

-

Obtain the anti-theft radio security code.

-

Switch the ignition off.

-

Disconnect the battery Ground (GND) strap

-

After reconnecting battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows.

1

-

Wiper blade

2

-

Wiper arm

3

-

Cap

4

-

Hex nut M8
-

19 Nm (14 ft. lb.)

5

-

Washer

6

-

Hex bolt M6
-

5 Nm (44 in. lb.)

7

-

Rubber grommet

8

-

Spacer

9

-

Hex nut M8
