Wiper Switch: Locations

Steering Column Switches, Assembly

CAUTION!
Before beginning repairs on the electrical system:

-

Obtain the anti-theft radio security code.

-

Switch the ignition off.

-

Disconnect the battery Ground (GND) strap.

-

After reconnecting battery, re-code and check operation of anti-theft radio.

-

Special safety precautions apply to vehicles equipped with airbags.

1

-

Airbag/cover for horn plate

2

-

Hex nut
-

67 Nm (49 ft. lb.)

3

-

Steering wheel

4

-

Spacer

5

-

Screws

6

-

Switch: turn signal, cruise control system, high/low beam and headlight flasher

7

-

Switch: windshield/rear window wiper and wiper/washer

8

-

Trim-upper part

9

-

Trim-lower part
