Golf Mk6
Repairing LuK clutch |
1 - | Dual-mass flywheel |
q | Removing and installing → Rep. gr.13 |
q | Ensure that centring pins fit tightly |
q | Contact surface for clutch lining must be free of grooves, oil and grease |
2 - | Clutch plate |
q | Allocation → Electronic parts catalogue „ETKA“ |
q | Removing and installing → Chapter |
q | Renew only together with SAC pressure plate. |
q | Installation position: → Fig.. |
3 - | SAC pressure plate |
q | SAC means „self-adjusting clutch“. |
q | Renew only together with clutch plate. |
q | Allocation → Electronic parts catalogue „ETKA“ |
q | Removing and installing → Chapter |
q | Check ends of diaphragm spring → Fig. |
q | Check spring connections and riveted connections → Fig.. |
q | From approx. 05 11: release bearing with additional plastic washer → Fig., pressure plate adapted → Fig. |
4 - | M6 bolt, 13 Nm, M7 bolt, 20 Nm |
q | Loosen or tighten diagonally in small steps |
