Golf Mk6

Installing windscreen wiper system

Installing windscreen wiper system
–  Install wiper frame in reverse order of removal.
  Note
Note when installing that securing pin -2- of wiper frame must be inserted in grommet -1- in plenum chamber bulkhead.
–  Tighten threaded connections to torques specified in assembly overview → Chapter.
–  Fit connector to wiper motor connection and lock in position.
–  Install plenum chamber cover → General body repairs, exterior; Rep. gr.64.
–  Reconnect battery → Chapter.
–  Install wiper arms → Chapter.
  N92-10086
