Drive Belt: Diagrams

Ribbed Belt, Routing

4-cylinder TDI - PD engine

1

-

Tensioning roller

2

-

Pulley - generator

3

-

Pulley - a/c compressor

4

-

Ribbed belt - crankshaft/vibration damper, tensioning roller, generator, a/c compressor and power steering pump

5

-

Pulley - power steering pump

6

-

Pulley - crankshaft/vibration damper

-

Belt drive for vehicles without air conditioning

-

Belt drive for vehicles with air conditioning
