Volkswagen Jetta L4-2.0L (BEV) (2004)03 · Maintenance
03 · Maintenance

Alignment (Alignment Specifications): Specifications (page 4 of 9)

Make
Volkswagen
Model
Jetta
Engine
L4-2.0L (BEV)
Year
2004
Section
Alignment › Specifications
MaintenanceAlignment Specifications · page 4 of 9
background image

Only by moving the subframe is it possible to change camber slightly.
-

Loosen bolts -1 - and - 2 - .

-

Move subframe to equalize camber on both sides.

Check caster; caster can also change when moving subframe.
Then check the caster angle afterward.


-

Secure subframe with new bolts.

Fastener/location - Tightening torques:

Subframe to body Bolt position - 1 - Use new bolts! ......................................................................  100 Nm (74 ft. lbs.) an additional 1/4 turn 90°
Subframe to body Bolt position - 2 - Use new bolts! .......................................................................  100 Nm (74 ft. lbs.) an additional 1/4 turn 90°
