Jetta V6-2.8L (AFP) (1999)
Hose/Line HVAC: Specifications
A/C Oil Capacity
A/C Oil Capacity
Type
Production Date
Capacity
Part numbers are for reference only. Always contact the
parts department for the latest part number in formation.
Golf/Jetta/GTI
From 10/98
135 +/- 15 CC
This is the total A/C System Refrigerant oil capacity.
Replacement A/C Compressors Supplied by the parts
department are filled with 135 cc of refrigerant oil.
Refrigerant (PAG) oil R-134a, distribution
The total refrigerant oil quantity is distributed in the
refrigerant circuit as follows:
Compressor
approx. 50%
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil into the new pad
before installation.
Condenser
approx. 10%
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil (as indicated above)
into the new pad before installation.
Suction pipe
approx. 10%
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil (as indicated above)
into the new pad before installation.
Discharge pipe
--
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil (as indicated above)
into the new pad before installation.
Evaporator
approx. 20%
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil (as indicated above)
into the new pad before installation.
Receiver drier
approx. 10%
When replacing refrigerant circuit components, fill an
appropriate amount of refrigerant oil (as indicated above)
into the new pad before installation.
