Coolant Line/Hose: Diagrams

Coolant hose connection diagram

1- Heater core
2- Lower coolant pipe
3- Expansion tank
4- Oil cooler
5- Intake manifold
6- Lower coolant hose
7- Upper coolant hose
8- Radiator
9- Upper coolant line

10- Coolant

-

pump/coolant regulator

11- Turbocharger
12- Cylinder

-

head/Cylinder block

13- Connecting piece
