Drive Belt: Diagrams
Ribbed Belt, Routing Diagrams
1. Pulley - Generator (GEN)
2. Ribbed belt - generator, power steering pump, coolant pump, crankshaft, tensioning roller, viscous fan and a/c compressor => table
3. Pulley - power steering pump
4. Pulley - viscous coolant fan
5. Pulley - a/c compressor
6. Pulley - crankshaft
7. Tensioning roller
